Clean Room Panels

Wall/ Ceiling Panels

Modular Wall / Ceiling panel systems have several unique features to build state of the art clean rooms and other controlled environment for various applications. Alternate surfaces and cores, however, are available to meet the requirements of any type of clean room applications. We will be happy to provide a customized quote based on your scientific requirement and applications. Self-bearing wall provided in modular units consisting of flush surfaces for easy cleaning and for complying with GMP requirements. Practically low maintenance, Good stability due to advanced architectural design. Attractive appearance custom designed solutions from a single room to complete departments. Full modularity, easy modularity, easy to assemble and dismantle.

A perfect ceiling makes a perfect clean room, Ultrafil Ceiling systems are designed to fit every requirement and adhere to strangle stringent quality standards that fi ts in seamlessly with the rest of the room panelling. The ceiling panels are fastened to profile that are placed on a particle tight extruded aluminium grid matrix with silicone sealant.

Specifications

DESCRIPTION TECHNICAL SPECIFICATIONS
Type of panel Wall / Ceiling (Walkable / Non Walkable) / Raiser Panel
Panel thickness 30 / 50 / 80 / 100 mm
Sheet thickness 0.6 / 0.8 mm
MOC Both side PPGI / PCGI / SS 304 Matt finish
Panel Infill Puff/ Mineral Wool / RockWool
Connecting Profile AL / GI
Connecting Profile type M – Section / Tung & groove
Bottom track U – type channel / R70 AL extrusion
Color RAL – 9001 / 9002 (As per requirement)
Ceiling panel hanging AL T – Grid / AL Extrusion ceiling grid
Coving requirement R – 50 / R – 70 AL extrusion
Maximum panel height 6 mtrs
